Reference Manual for the 108 Mbps Wireless Firewall Router WGT624 v3
Maintenance 6-3
v3.0, December 2005
DHCP If set to None, the router is configured to use a fixed IP address on the
WAN.
If set to Client, the router is configured to obtain an IP address
dynamically from the ISP.
IP Subnet Mask This field displays the IP Subnet Mask being used by the Internet (WAN)
port of the router.
Domain Name Server Displays the address of the current Domain Name Server
LAN Port These parameters apply to the Local (WAN) port of the router.
MAC Address This field displays the Media Access Control address being used by the
LAN port of the router.
IP Address This field displays the IP address being used by the Local (LAN) port of
the router. The default is 192.168.1.1.
DHCP Identifies if the router’s built-in DHCP server is active for the LAN
attached devices.
IP Subnet Mask This field displays the IP Subnet Mask being used by the Local (LAN)
port of the router. The default is 255.255.255.0
Wireless Port These parameters apply to the Wireless port of the router.
Name (SSID) This field displays the wireless network name (SSID) being used by the
wireless port of the router. The default is NETGEAR.
Region This field displays the geographic region where the router being used. It
may be illegal to use the wireless features of the router in some parts of
the world.
Channel Identifies if the channel the wireless port is using. See “Wireless
Communications” in Appendix B for a link to a document that details the
frequencies used on each channel.
Mode Indicates the current mode (g & b, g only, b only, or Auto 108 Mbps)
Wireless AP Indicates if the Access Point feature of the router is enabled. If not
enabled, wireless devices will not be able to connect to the network.
Broadcast Name Indicates if the wireless router is broadcasting its SSID.
Table 6-1. Menu 3.2 - Wireless Router Status Fields (continued)
Field Description
