Reference Manual for the 108 Mbps Wireless Firewall Router WGT624 v3
4-14 Content Filtering
v3.0, December 2005
Viewing Logs of Web Access or Attempted Web Access
The log is a detailed record of what websites you have accessed or attempted to access. Up to 128
entries are stored in the log. Log entries will only appear when keyword blocking is enabled, and
no log entries will be made for the Trusted User. An example is shown below:
Log entries are described in Table 4-1
Figure 4-8
Table 4-1. Log entry descriptions
Field Description
Action This field displays whether the access was blocked or allowed.
Destination IP The name or IP address of the website or newsgroup visited or
attempted to access.
Source IP The IP address of the initiating device for this log entry.
Date and Time The date and time the log entry was recorded.
