Wireless-N 300 USB Adapter WNA3100 User Manual
2-10
v1.0, December 2009
Wireless Network Name (SSID) and Security Settings
If you do not use WPS, then you need to know the security settings to join a secured wireless
network. You can save the settings in a profile. You can also print this page, fill in the wireless
network settings, and put it in a safe place for future reference.
• Network Name (SSID) ______________________________
• If WPA2-PSK or WPA-PSK authentication is used:
Passphrase:
______________________________ These characters are case-sensitive.
• If WEP authentication is used:
– WEP encryption key size. Circle one: 64-bit or 128-bit.
– Data encryption (WEP) keys. There are two methods for creating WEP data encryption
keys. Whichever method you use, record the key values in the spaces below.
• Passphrase method:
______________________________ This is case-sensitive. Not
all wireless devices support the passphrase method.
• Manual method. These values are not case-sensitive. For 64-bit WEP, enter 10 hex
digits (any combination of 0–9 or a–f). For 128-bit WEP, enter 26 hex digits.
Key 1:
_____________________________ Key 2: _____________________________
Key 3:
_____________________________ Key 4: _____________________________
Setting Up WPA-PSK [TKIP] or WPA2-PSK [AES] Security
To configure WPA-PSK (TKIP) or WPA2-PSK (AES) security:
1. Run the WNA3100 v1 Smart Wizard.
a. Make sure that the wireless-N USB adapter is fully inserted in a USB port in your
computer.
b. Use the icon to open the Smart Wizard. The Settings tab displays.
2. Configure the security settings.
a. In the Profile field, select the profile, or type in a profile name.
b. In the Network Name (SSID) field, select the network, or enter the SSID.
Note: You will not get a wireless network connection unless the network SSID
matches exactly what is configured in the access point.
To Next Page
