NETGEAR WNA3100 - Wireless-N 300 USB Adapter User Manual

Wireless-N 300 USB Adapter WNA3100 User Manual
2-4
v1.0, December 2009
Using Push 'N' Connect to Join a Network
If there is a WPS network in your area, you can use Push 'N' Connect to join it and automatically
configure the wireless security settings for your adapter.
To join a network:
1. On the Networks tab, select the network and click Connect.
If the router supports Push 'N' Connect (also called WPS), the following screen displays:
2. Press and hold the push button on the side of the wireless-N USB adapter for 2 seconds. The
LED flashes.
3. Follow the wizard steps to push the router’s WPS button within 2 minutes, and connect to the
wireless network.
Creating a Profile to Connect to a Wireless Network
You can create and save a profile from the Settings tab.
To set up a profile:
1. Click the icon to open the Smart Wizard. The Settings tab displays:
Note: To use Push 'N' Connect you need to know the location of the wireless router, and
you must have access to the router so that you can push its WPS button.
Figure 2-3

NETGEAR WNA3100 - Wireless-N 300 USB Adapter Specifications

General

Interface	USB 2.0
Frequency Band	2.4 GHz
Data Transfer Rate	Up to 300 Mbps
Security	WEP, WPA, WPA2
Standards	IEEE 802.11b/g/n
Antenna	Internal
Operating Systems Supported	Windows XP, Vista, 7
Wireless Type	802.11b/g/n
