Table 1. Front panel LED descriptions
LED Description
Power/Test • Solid amber. The unit is starting up after being powered on.
• Solid green.
The power is on, and the router is ready.
• Blinking amber. A firmware
update is in progress.
• Blinking green. The firmware is corrupt.
• Off. Power is not supplied to the router.
Internet
• Solid amber. The IP address has not been acquired.
• Solid green. An IP addre
ss has been received; ready to transmit data.
• Off. No Ethernet
cable is connected between the router and the modem.
2.4 GHz
• Solid blue. The wireless radio is operating.
• Off. The
wireless radio is off.
5 GHz
• Solid blue. The wireless radio is operating.
• Off. The
wireless radio is off.
LAN ports
1–4
• Solid green. Th
e LAN port has detected a 1,000 Mpbs link with an attached device.
• Solid amber. The
LAN port has detected a 10/100 Mbps link with an attached device.
• Off. No link is detected on this port.
USB
(2 LEDs)
• Solid. The USB device had been accepted by the router and is ready to be used.
• Blinking. The USB device is in use.
• Off. No USB device
is connected, or the Safely Remove Hardware button has been clicked
and it is now safe to remove the attached USB device.
Hardware Setup
10
N900 Wireless Dual Band Gigabit Router WNDR4500
The WLAN and WPS buttons toggle the WLAN and WPS functions on and off.
•
WLAN On/Off button. Pressing and holding the wireless LAN button for 2 seconds
turns the 2.4 GHz and 5 GHz wireless radios on and off. If the 2.4 GHz and 5 GHz LEDs
are lit, then the
wireless radio is on. If these LEDs are off, then the wireless radios are
turned off and you cannot connect wirelessly to the router.
•
WPS button. You can use this button to use WPS to add a wireless device or
computer to your wireless network. The LED below th
e WPS button blinks green when
the router is trying to add the wireless device or computer. The LED stays solid green
when wireless security is enabled in the router.
