Supplemental Information
45
Powerline Music Extender XAU2511
Technical Specifications
Feature Specification
Data and routing protocols IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-T), IEEE 1901
AC input 100–240V~, 0.2A (max.)
Power consumption 9.6W (max.)
Dimensions 131 x 60 x 35 mm
Weight 0.245 kg (0.54 lb)
Socket ratings Recommended use max. 10A
Operating temperature 0 to 40C (32º to 104ºF)
Operating humidity 10–90% maximum relative humidity, noncondensing
Storage humidity 5–95% maximum relative humidity, noncondensing
Security encryption type 128-bit AES
MAC addresses 64: number of nodes that can be added to a single network
Bandwidth 200 Mbps
Compatibility Not HomePlug v1.0 or HomePlug v1.0 Turbo compatible
Data transfer rate Up to 200 Mbps with real throughput greater than 80 Mbps
Frequency band 2–30 Mbps
Modulation type OFDM symbol modulation
Electromagnetic emissions FCC Part 15 Class B; CE-EMC Class B; 3-home FCC Certificate
Safety agency approvals UL (UL 60950-1 2nd Edition);
cUL (CSA C22.2 No. 60970-1-07 2nd Edition);
TUV CB (IEC 60950-1:2005 +A1);
TUV GS (EN 60950-1:2006+A11+A1+A12);
CE LVD (EN 60950-1:2006+A11:2009+A1:2010+A12:2011)
USB 1 port: USB v2.0
