Reset Button
The switch provides a Reset button on the front panel so that you can reboot the switch. Save the
configuration before you press the Reset button.
To reboot the switch using the Reset button:
1. Insert a device such as a straightened paper clip into the opening.
2. Press the recessed Reset button for about three seconds.
The switch reboots.The front panel LEDs turn off and light again as the switch performs its power-on
self-test (POST).
Factory Defaults Button
To reset the switch to factory default settings using the Factory Defaults button:
1. Insert a device such as a straightened paper clip into the opening.
2. Press the recessed Factory Defaults button for more than three seconds.
The switch reboots.The front panel LEDs turn off and light again as the switch performs its power-on
self-test (POST).
CAUTION:
If you press and hold the button for more than 15 seconds, the switch
enters Recovery Mode, and the Power LED turns from green to yellow.
Use Recovery Mode only as directed by NETGEAR support. If the switch
enters Recovery Mode, power cycle the switch or press the Reset button.
Then follow Step 1 and Step 2 in the previous procedure (see Reset
Button on page 19) to make sure the switch is reset to factory default
settings.
Hardware Overview
19
8-Port, 12-Port, and 16-Port Gigabit Smart Managed Pro Switch

NETGEAR XS708T Specifications

General

Switch type	Managed
Switch layer	L2+/L3
Quality of Service (QoS) support	Yes
USB 2.0 ports quantity	1
SFP+ module slots quantity	2
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity	8
Certification	CE, FCC Cl. A, VCCI Cl. A, Cl. A EN 55022 (CISPR 22), Cl. A C-Tick, EN 55024, CCC
Product color	Black
LED indicators	Activity, Link, Power
Number of fans	1 fan(s)
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN
Cable types supported	Cat5e, Cat6, Cat6a, Cat7
Copper ethernet cabling technology	10GBASE-T
Noise level	29.1 dB
Flash memory	256 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276832 h
Jumbo frames	9000
Latency (10 Gbps)	3.012 µs
MAC address table	16000 entries
Packet buffer memory	2 MB
Number of static routes	32
DHCP features	DHCP server, DHCP client
Security algorithms	802.1x RADIUS
Access Control List (ACL) rules	100
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	96 W
Operating altitude	0 - 3000 m
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2980 g
