I/Os & General Information
INSTRUMENT INPUT
CONNECTOR: 1/4 TRS-F
IMPEDANCE: 1MΩ
MAX INPUT LEVEL: +10dBu
COMBO CAPTURE INPUT
CONNECTOR: XLR-F + 1/4 TRS-F
TS IMPEDANCE: 1MΩ
XLR IMPEDANCE: 45kΩ
MAX INPUT LEVEL: +10dBu
BOOST GAIN: +26dB
TRS OUTPUTS 1L/2R
CONNECTOR: (2) 1/4 TRS-F
IMPEDANCE: 560Ω
MAX OUTPUT LEVEL: +10dBu (Unbalanced) / +16dBu (Balanced)
HEADPHONES OUTPUT
CONNECTOR: 3.5MM TRS-F
MAX OUTPUT POWER: 55mW into 20Ω
EXP/MIDI INPUTS
EXPRESSION CONNECTOR: 1/4 TRS-F
MIDI CONNECTOR: MIDI TRS Type A
