Neural Capture Calibration Settings
Capture Mode will give you access to the calibration settings.
Ensure the microphone position (if you are using a microphone in front of a speaker cabinet)
and the target device's settings are set as desired, and the GAIN knob on the Nano Cortex is at
the minimum position (0%).
• • •
MAIN CONTROLS
GAIN: Turn it clockwise to increase the CAPTURE INPUT gain up to +24dB. Its LED ring is a
meter that measures the CAPTURE INPUT
LEVEL: Controls the overall output volume of the Nano Cortex (OUTPUT 1L and 2R).
FOOTSWITCH II: Turn it clockwise or counterclockwise to navigate IR slots. The LEDs will
light up according to the slot selected. Navigate to the last position, where the LEDs are not
lit, to bypass the IR Loader.
CAPTURE: Press-and-hold for 3 seconds to begin the Capture process.
ADDITIONAL CONTROLS
HP LEVEL: Headphones output volume control.
GND SWITCH: Toggles ON/OFF the ground lift on OUTPUTS 1L and 2R. This feature helps to
reduce unwanted noise by interrupting the ground loops coming from external sources.
BOOST SWITCH: Toggles ON/OFF the analog boost circuit. When enabled, it boosts the
CAPTURE INPUT +26dB.
• • •
GAIN KNOB BEHAVIOR
In Capture Mode, the GAIN LED ring is a meter that measures the CAPTURE INPUT.
