Performance Mode Controls
GAIN: Sets the amount of gain for the current Neural Capture.
BASS: Sets the amount of bass frequencies for the current Neural Capture.
MID: Sets the amount of middle frequencies for the current Neural Capture.
TREBLE: Sets the amount of high frequencies for the current Neural Capture.
AMOUNT: Controls the amount of the active effect that is added to the direct signal.
LEVEL: Controls the master output volume (OUTPUTS 1L and 2R).
HP OUT: Headphones output volume control.
• • •
KNOB OPERATION MODES
Turn the knobs clockwise or counterclockwise to change their values.
