Model 3100 Analyzer Instruction Manual
Page 40
Manual file name: MN-A-0005, Rev. C
Manual P/N: C5-06-4900-16-0
Part number Description
Range ID voltage 0.1 – 9.9 PPM 3.13 VDC + 0.1VDC
10.0 – 99.9 PPM 3.75 VDC + 0.1VDC
100.0 – 999.9 PPM 4.38 VDC + 0.1VDC
1000 – 9999 PPM 5.00 VDC + 0.1VDC
1 – 9.99 % 6.25 VDC + 0.1VDC
10 – 99.9 % 8.13 VDC + 0.1VDC
Relay outputs Alarm-1
Field Adjustable Form C (SPDT) Voltage-free, 5A @
250 VAC, 5A @ 30 VDC (configurable to fail-safe/non
fail-safe and ascending/descending activation)
Alarm-2
Field Adjustable Form C (SPDT) Voltage-free, 5A @
250 VAC, 5A @ 30 VDC (configurable to fail-safe/non
fail-safe and ascending/descending activation)
Fault
Non-adjustable Form B (SPST) Voltage-free, 5A @
250 VAC, 5A @ 30 VDC (non-fail-safe activation, non-
configurable)
Heater OK
Non-adjustable Form B (SPST) Voltage-free, 5A @
250 VAC, 5A @ 30 VDC (non-fail-safe activation, non-
configurable)
Measurement range 0-10 PPM | 0-100 PPM | 0-1000 PPM | 0-10,000 PPM | 0-10% | 0-100 % O2
Accuracy ± 2.0% of range @ standard temperature and pressure
Response time T
90
< 5 seconds
Warm-up time None
Humidity 0-95% non-condensing
Power VAC unit 90–264 VAC, 47–63 Hz, Single Phase, 3 Watts
VDC unit 11–30 VDC, 3 Watts
Operating temperature 32° to 122° F (0° to 50° C)
Storage temperature 23° to 122° F (-5° to 50° C)
Weight 2 Lbs. (0.9 Kg)
Mechanical Faceplate Height 3.75”x Width 7.00” | NEMA 4, IP66
Panel cut-out Height 2.91” x Width 6.20”
Electronics
enclosure
Height 2.81“ x Width 5.98” x 3.60” Depth | NEMA 1, IP20
Warranty 1 year from date of shipment
