5.3 Appendix C – Analyzer factory configuration settings
Alarm and relay setup information
Alarm-1/Alarm-2 Relays Failsafe/Non-Failsafe Non-fail-safe
Alarm-1/Alarm-2 Relay Ascending/Descending Ascending
Alarm-1 Trigger Level 50 PPM
Alarm-2 Trigger Level 100 PPM
Display range Analog voltage range
0–10 PPM Fixed 0–1 VDC X
0–100 PPM Fixed 0–5 VDC
0–1,000 PPM Fixed 0–10 VDC
0–10,000 PPM Fixed
0–10 % Fixed
Relay disable after
CAL/setup
0–100 % Fixed 120-seconds X
Auto Ranging X
RS-232 baud rate RS-232 dump rate
300 BPS 1-second X
1200 BPS
2400 BPS
4800 BPS
9600 BPS X
19200 BPS
38400 BPS
RS-232 timed output format
Output on Request Only
Human Readable Format X
Machine Code
Machine Code With Checksum
Tab Delimited (Spreadsheet)
Supply voltage
90 – 264 VAC, 47 – 63 Hz X
11 – 30 VDC
