Instruction Manual Model 3100 Analyzer
Manual P/N: C5-06-4900-16-0 Manual file name: MN-A-0005, Rev. C Page 39
5 Appendices
5.1 Appendix A – Spare parts list
Part number Description
5-06-4900-16-0 Instruction manual
C1-11-1220-03-0 Vac fuses for power supply board – 1A, 250 VAC, Slo-Blo – for Vac units only
C6-01-1000-73-0 RSM / Analyzer interface cable
C1-17-0052-00-0 Replacement terminal block – TB1
C1-17-0142-00-0 Replacement terminal block – TB2
C1-17-0112-00-0 Replacement terminal block – TB3
5.2 Appendix B – Specifications
Part number Description
Sensor type Rapid-response zirconium oxide, ZR100
Display
0.75” 7-segment LED digital display, 4 characters (displays O2 from 0.1 PPM
to 100%)
Display resolution 0.1 – 9.9 PPM X.X
10.0 – 99.9 PPM XX.X
100.0 – 999.9 PPM XXX.X
1000 – 9999 PPM XXXX
1 – 9.99 % X.XX
10 – 99.9 % XX.X
100% XXX.X
Color-coded LEDs RUN Green
FAULT Yellow
ALARM-1 Red
ALARM-2 Red
Serial service port Bi-directional RS-232
Analog voltage output 0–1, 0–5, or 0–10 VDC
Analog current output
Non-isolated 4 – 20 mA, 12 VDC, negative ground; powered by analyzer;
maximum electrical load 250 Ohms
