Newport LDC-3706 Series User Manual

December 2019 60 LDC-3706 Series Laser Controller
NAME FUNCTION INSTrument
SOURce[1]:CURRent:LIMit:LOW <nrf> Set lower TEC current limit. TEC
SOURce[1]:CURRent:LIMit:LOW? Report lower TEC current limit. TEC
SOURce[1]:CURRent:LIMit[:AMPLitude] <nrf> Set laser current limit. LAS
SOURce[1]:CURRent:LIMit[:AMPLitude]? Report laser current limit. LAS
SOURce[1]:CURRent:RANGe <nrf> Set range of laser current source. LAS
SOURce[1]:CURRent:RANGe?
Report currently selected laser
current source range.
LAS
SOURce[1]:CURRent[:LEVel][:IMMediate] <nrf>
Set control setpoint for LDI or
ITE, depending on the currently
selected instrument mode.
LAS, TEC
SOURce[1]:CURRent[:LEVel][:IMMediate]?
Report control setpoint for LDI or
ITE, depending on the currently
selected instrument mode.
LAS, TEC
SOURce[1]:FUNCtion:[:MODE] <string>
Set the operating mode for the
currently selected instrument mode.
LAS, TEC
SOURce[1]:FUNCtion[:MODE]?
Report the operating mode for the
currently selected instrument mode.
LAS, TEC
SOURce[1]:POWer:LIMit <nrf> Set the photodiode power limit. LAS
SOURce[1]:POWer:LIMit?
Report the photodiode power limit
setpoint.
LAS
SOURce[1]:POWer[:LEVel][:IMMediate] <nrf> Set the laser diode power setpoint. LAS
SOURce[1]:POWer[:LEVel][:IMMediate]?
Report the laser diode power
setpoint.
LAS
SOURce[1]:RESistance:LCONstants:DERivative <nrf>
Set the “D” term for the TEC
controller PID control loop.
TEC
SOURce[1]:RESistance:LCONstants:DERivative?
Report the “D” term for the TEC
controller PID control loop.
TEC
SOURce[1]:RESistance:LCONstants:INTegral <nrf>
Set the “I” term for the TEC
controller PID control loop.
TEC
SOURce[1]:RESistance:LCONstants:INTegral?
Report the “I” term for the TEC
controller PID control loop.
TEC
SOURce[1]:RESistance:LCONstants[:GAIN] <nrf>
Set the “P” term for the TEC
controller PID control loop.
TEC
SOURce[1]:RESistance:LCONstants[:GAIN]?
Report the “P” term for the TEC
controller PID control loop.
TEC
SOURce[1]:RESistance:PROTection:LOW <nrf>
Set the TE controller resistance
lower limit.
TEC
SOURce[1]:RESistance:PROTection:LOW?
Report the TE controller resistance
lower limit.
TEC
SOURce[1]:RESistance:PROTection[:HIGH] <nrf>
Set the TE controller resistance
upper limit.
TEC
SOURce[1]:RESistance:PROTection[:HIGH]?
Report the TE controller resistance
upper limit.
TEC
SOURce[1]:RESistance:SPOint <nrf> Set the TE controller resistance TEC
