NEWTON S 19
SYSTEM OPERATION MANUAL
The top part sets the control system tuning. For each axis, tilt, roll and pan, there are four parame-
ters to set. These values can be modified individually just as any other setting, or as a group of three (P,
I and D together) for a given axis. When modifying a group the values are changed by using the three
encoders on the right side, point 22-24. In group change mode the up/down buttons switch between
the axes.
! NOTICE !
After updating any settings on RMT SETTINGS you need to explicitly
save them to the head by selecting SAVE REMOTE. Otherwise the settings
will be lost once the Newton S is power cycled.
Figure 5.2: Newton C1 Settings - Remote settings tab
DO NOT DISTRIBUTE
Copyright © 2019 Newton Nordic AB
