2 Physical Layout
2.1 NEWTON S
6
5
4
3
2
1
8
7
Figure 2.1: Newton S overview 1
Table 2.1: Overview Descriptions
Item Description
1,3 Battery
2 Attachment points
4 Battery clamp
5 Side-to-side lock clamp
6 Cradle connectors
7 Pan balance adjustment screw
8 Pan-box connectors
