Table 5.3: Newton C1 Settings - Lens tab
Setting Range Description
FOCUS MIN Minimum focus value shown in GUI
FOCUS MODE NORMAL
INVERT
Invert mode of focus wheel
FOCUS DRIVE MODE NORMAL
INVERT
Invert mode of focus motor
IRIS CONTROL ENABLED
DISABLED
Enable or disable IRIS control
IRIS OPEN 1.0 –
IRIS CLOSED
Open IRIS value shown in GUI
IRIS CLOSED IRIS OPEN –
64
Closed IRIS value shown in GUI
IRIS STEP 0.5 Step size of values shown in GUI
IRIS MODE NORMAL
INVERT
Invert mode of iris wheel
IRIS DRIVE MODE NORMAL
INVERT
Invert mode of iris motor
ZOOM NEAR 10 – ZOOM FAR Zoom near value shown in GUI
ZOOM FAR ZOOM NEAR –
1000
Zoom far value shown in GUI
ZOOM SPEED 10 – 200% Zoom speed
ZOOM MODE NORMAL
INVERT
Invert mode of zoom
ZOOM DEADBAND 0 – 100% Zoom control dead-band
ZOOM EXPO 0 – 100% Zoom control exponential
ZOOM MODE NORMAL
INVERT
Invert mode of zoom wheel
ZOOM DRIVE MODE NORMAL
INVERT
Invert mode of zoom motor
ZOOM SPEED MODE USE
DISABLE
Use speed-based zoom control if avail-
able
Preset 1 FOCUS+ZOOM
FOCUS
ZOOM
Set preset mode
Preset 2 FOCUS+ZOOM
FOCUS
ZOOM
Set preset mode
Preset 3 FOCUS+ZOOM
FOCUS
ZOOM
Set preset mode
5.4 COMMUNICATIONS
5.4.1 RADIO
Configuration of the radio modems is done in the RADIO settings tab. To use a radio modem the
modem must be enabled. To save the configuration, select SAVE CONFIG.
When the Newton C1 is used together with a Newton S for the first time the radios must be paired.
The pairing procedure works the following way:
1. Turn off the remote head
