Newton S - A Technical Specification; Mechanical

NEWTON S 30
SYSTEM OPERATION MANUAL
A Technical Specification
A.1 NEWTON S
A.1.1 MECHANICAL
Table A.1: Newton S - Mechanical
Parameter
Min
Typ Max
Length
1
35 cm
Width
1
30 cm
Height
1
35 cm
Weight
1
7.0 kg
1
Without camera
Table A.2: Newton S - Power supply
Parameter
Min
Typ Max
Power input
Input voltage
12 V
24 V 26 V
Input current 16 A
Pan-box power out
Output voltage
1
12 V
24 V 26 V
Output current 3.3 A
Cradle power out
Output voltage
14.5V
15 V 15.5 V
Output current
2
6.5 A
Output power
2
105 W
1
Unregulated input/battery voltage
2
Depends on input/battery voltage
Table A.3: Newton S2 - Newton Battery
Parameter
Min
Typ Max
Voltage
12 V
14.4 V 16 V
Current 20 A
Capacity 89 Wh
Table A.4: Shipping/hard-case
Parameter
Min
Typ Max
Length 62 cm
Width 55 cm
Height 29 cm
Weight
1
19 kg
1
Including two batteries and charger
