- Device Features
USB-Link™ 2 Wi-Fi Edition Installation and Setup Manual 9
Device Features
The following illustration details the features of the USB-Link™ 2 device.
B
C
D
E
A
F
Reset Button
Figure 2.1 USB-Link™ 2
Legend
A—Vehicle Port D—Wireless LED
B—Power LED E—Fault LED
C—Data LED F—USB Port
