10 USB-Link™ 2 Wi-Fi Edition Installation and Setup Manual
Chapter 2 • Introducing the USB-Link™ 2 Wi-Fi Edition
The following table outlines the features called out in Figure 2.1.
Feature
What It Does
Vehicle Port Connects the USB-Link™ 2 to a vehicle.
Power LED
Illuminates when the device receives power.
Data LED Illuminates when the device is receiving data from
the vehicle.
Wireless LED Mini Access Point Mode:
• Illuminates solid when a client PC conn
ects to
the device.
• Off when not connected.
Infrastructure Mode:
• Stays off when not associated with an Access
Point.
• Blinks every second when associated with a
netw
ork but no IP address assigned.
• Illuminates solid when successfully assigned
an IP address.
Fault LED Illuminates when a problem is detected.
USB Port Connects the device to your PC (wired
connec
tion).
The Reset Button
If you have configured your USB-Link™ 2 device in Infrastructure Mode (using the
USB-Link™ 2 Explorer), you can use the Reset button on the bottom of the device
to switch from Infrastructure Mode back to Mini Access Point Mode (the factory
default). Just push and hold the button until all the lights on the front of the device
flash, about five (5) seconds.
i For detailed information on the USB-Link™ 2 Explorer, see Using the
USB-Link™ 2 Explorer in Chapter 3 of this manual.
