GEO M10 HARDWARE SETUP PROCEDURE Page 25/79
MSUB15 features a 4 points rigging system:
- Upper connection features retractable rigging links that can be unlocked from the sides
- Lower connection features semi-auto lock rigging points that lock with latches on the sides
Front and rear rigging points are identical so that MSUB15 count be mounted reverse for cardiod setups
MSUB15 upper rigging points MSUB15 lower rigging points
Angle splay setting sequences are as follow:
- MSUB15 to MSUB15: 0°
- MSUB15 to GEO M1012 (or M1025): -12° / -9° / -6° / -3° / 0° / +3° / +6° / +9°
6.2.5 Accessories
GEO M10 & MSUB15 accessories are:
