Nexo GEO M10

Page 40/79 GEO M10 HARDWARE SETUP PROCEDURE
IMPORTANT
Ensure that bumper quick release pins are properly locked into GEO M10, and that all
AutoRig
TM
and rear pins are locked
Disassembly
- On both side, pull AutoRig
TM
and hold the side knob (AutoRig
TM
remains in the open position).
- Remove the rear quick release pin BL820
- Unlock the GEO M10 link bar by pulling the latch.
- Disassemble GEO M10s
