Nexo Geo M620

GEO M6 SETUPS ON NEXO TD CONTROLLERS Page 11/62
4 GEO M6 SETUPS ON NEXO TD CONTROLLERS
4.1 NXAMP TDControllers
As of this manual printing date, load 3.22 features the setups listed in below table in the “NEXO
configurations” menu.
NEXO recommended setups
CH1
CH2
CH3
CH4
'M620-LS18 120Hz'
'1-3 Boxes'
LS18 (bridged with CH2)
N/A
M620
M620
'M620-LS18 120Hz'
'4-12 Boxes'
LS18 (bridged with CH2)
N/A
M620
M620
'M620-70Hz'
'4 Ch. 1-3 Boxes'
M620
M620
M620
M620
'M620-70Hz'
'4 Ch. 4-12 Boxes'
M620
M620
M620
M620
'M620-120Hz'
'4 Ch. 1-3 Boxes'
M620
M620
M620
M620
'M620-120Hz'
'4 Ch. 4-12 Boxes'
M620
M620
M620
M620
- Setups “1-3 Boxes” are to be used in small configuration (pole stand, lip fill, under-balcony);
- Setups “4-12 Boxes” are to be used in larger arrays – typically flown;
- Frequency value is high-pass filter cut-off point.
Additionally, “Custom configurations menu” allows to build any combination of NEXO speakers –
including GEO M6Bass with:
- Full phase compatibility from 20 Hz to 20kHz.
- Choice between 85 Hz and 120 Hz X-over point between Nexo LS or RS subwoofers and Geo M6.
NEXO Custom setups
M620 4-12 BOXES 70Hz-20kHz
M620 4-12 BOXES 85Hz-20kHz
M620 4-12 BOXES 120Hz-20kHz
M620 1-3 BOXES 70Hz-20kHz
M620 1-3 BOXES 85Hz-20kHz
M620 1-3 BOXES 120Hz-20kHz
M6B 70Hz-180Hz
M6B 85Hz-180Hz
Please consult www.nexo-sa.com for upgrade releases.
