GEO M6 HARDWARE SETUP PROCEDURE Page 25/62

Described configurations

8.2.5

FIX INSTALLATION APPLICATIONS

TOURING APPLICATIONS

SECTION 8.3.1

1 to 3 GEO M6 WALL MOUNTED

SECTION 8.3.2

1 to 3 GEO M6 CEILING MOUNTED

SECTION 8.3.3

4 to 12 GEO M6 CEILING MOUNTED

SECTION 8.3.4

1 to 3 GEO M6 POLE MOUNTED

SECTION 8.3.5

1 to 3 GEO M6 TRUSS MOUNTED

SECTION 8.3.6

1 to 6 GEO M6 STACKED ON SUB

SECTION 8.3.7

3 to 12 GEO M6 FLOWN
