Nexo Geo M620

Page 44/62 TECHNICAL SPECIFICATIONS
11.2 GEO M620 Module
System specifications 11.2.1
SYSTEM SPECIFICATIONS
GeoM620 with NEXO controller setup
Frequency Response
80 Hz - 19 kHz ±3dB
Usable Range @-6dB
75Hz - 20 kHz
Sensitivity 1W @ 1m
95 dB SPL Nominal
Nominal Peak SPL @ 1m
128 dB
HF Dispersion
80° or 120° Horizontal
Crossover Frequencies
LF-HF: 2 kHz Passive
Nominal Impedance
8
Recommended Amplifiers
450W per box (3 boxes max in parallel on one channel amplifier)
PRODUCT FEATURES
GeoM620
Components : LF]
HF
LF: 1x 6,5", 8 ohms long excursion driver
HF : 1x 1" throat driver on a BEA/FEA optimized HR Wavesource
Height x Width x Depth
191 x 373 x 260 mm
Weight : Net
9.7 kg
Connectors
2 x NL4 Speakon 4 poles
Construction
Lightweight Polyurethane composite
Fittings: Handles
Side “Geo” Handles
Front finish
Acoustic Fabric fitted front grill
SYSTEM OPERATION
Electronic Controller
The NEXO controller’s presets are precisely matched to the GeoM Series cabinets and include sophisticated protection.
Using GeoM Series cabinets without a properly connected NEXO controllers will result in poor sound quality and can
damage components.
Dispersion configuration
Flanges
Speaker Cabling
2+/2-
As part of a policy of continual improvement, NEXO reserves the right to change specifications without notice.
