Page 12/62 CONNECTION DIAGRAMS
5 CONNECTION DIAGRAMS
5.1 6 x GEO M620 stereo 2 x LS18 mono on NXAMP4x1
Channels 1 & 2 are bridge mono for 2xLS18, channel 3 & 4 drive 3 GEO M620 each
