NXES104 EXPANSION BOARD AND REMOTE CONTROL
(1) Input meters choice
Here you can choose between analog input meters or digital inputs (from Ethersound™
network) meters. Mixed mode is not accessible in this release. Click on the text
corresponding to the input you wish to monitor.
(2) Input meters
Here you can see the input meters for the four channels selected above.
(3) Delay Unit
This control is not accessible with this release: only meters is possible.
1 2 9 7 6 5 11 8 3 4 10 12
PAGE 57 OF 80
