PS
S
ERIES
P
ARTS
&
A
CCESS
ORIES
L
IST
Page
79
/
82
10
PS
S
ERIES
P
A
R
TS
&
A
CCESSORIES
L
I
ST
10.1
Modules & Control Electronics List
MODEL
DRAWING
DESCRIPTION
PS8
PS8 speaker
LS400
LS400 Subwoofer f
or PS8
PS10
R2
-L
PS10
R2
-R
PS10
R2
speak
er Left and Right versions
LS600
LS600 subwoofer
for PS10R2
PS15
R2
-L
PS15
R2
-R
PS15
R2
speak
er Left and Right versions
NX 242
–
ES4
Digital TDcontroller
PS8TD
Analogue PS8 T
DController for PS8
PS10TD-
R2
Analogue PS10 TDCon
troller for PS10R2
PS15TD-
R2
Analogue PS15 TDCon
troller for PS15R2
NXAMP4x1
Digital Powered Co
ntroller 4x1300W
NXAMP4x4
Digital Powered Co
ntroller 4x4000W
