4
Front Facing Camera - Parts and Controls (contd.)
Please see below to identify the parts and controls of your Dash Cam.
Right side:
1
5
2
3
4
Side Cover
Removable side cover, remember to replace the side cover before use.
Anti-Tamper Screw Insert
Insert thread for the anti-tamper screw.
USB Socket
Connect the supplied USB data cable here to connect the Dash Cam to a computer.
Note:
During normal use the car power cable is connected to the mount, not directly to
this socket.
SD Card Slot
Insert the MicroSD card here, taking care that the gold contacts are facing towards the mount.
Camera to Mount Locking Screw
The camera can be secured to the mount to prevent un-authorised removal,
see pages 31 for further details.
1
1
5 3
12
