Parts and Functions
Liquid crystal display
The portable DVD player is equipped with a liquid crystal display.
Liquid crystal display
Speakers
Control section
Remote sensor
1
2
3
4
1
2
3
4
5 Power indicator5
The remote control signals are received here.
Control buttons
Off: No power connection.
Main unit control section
-15-
1 2 3 4 5
1
2
3
4 5
Red: The player is set to standby mode.
Blue:The player is on. Turn on the power using ON button on the main unit or the STANDBY
button on the remote control unit.
6
ON OFF
