Parts and Functions
Main unit rear side
Support
1
The unit can stand with this device.
Main unit bottom side
1
2
Hole for Battery Pack
Nut for Battery Pack
Battery connector
3
1
2
3
How to stand
1
2
3
Pull out the support.
Draw out the support to a proper position .
Pull down the button to lock it.
1
2
3
-18-
1
1
1 3 2 1
1 2 3
LOCK
UNLOCK
LOCK
UNLOCK
Note:
Remember to insert back the rubber cover to 3. BATTERY CONNECTOR after
using the battery pack.
