Installation alternative
COMPATIBLE NIBE AIR/WATER HEAT PUMPS
Compatible NIBE air/water heat pump must be equipped
with a control board with display that has a software
version indicated in the following list as a minimum. The
control board version is displayed in the heat pump’s
display at start-up.
Software versionProduct
all versionsF2040-6
all versionsF2040-8
all versionsF2040-12
all versionsF2120-8
all versionsF2120-12
all versionsF2120-16
all versionsNIBE SPLIT HBS 05:
AMS 10-6 + HBS 05-6
AMS 10-8 + HBS 05-12
AMS 10-12 + HBS 05-12
VVM 320 can be connected to extra water heater.
Further option information is available at www.nibe.co.uk
and in the relevant assembly instructions for the ac-
cessories used. See page 69 for the list of the accessor-
ies that can be used with VVM 320.
The indoor module can be supplemented with an extra
water heater, if a large bath tub or other significant
consumer of hot water is installed. A mixer valve is then
installed on outgoing hot water from the water heater.
Water heater with immersion heater
If it is possible to use a water heater with an immersion
heater, connect it as illustrated below.
NIBE VVM 320Chapter 4 | Pipe connections18
