Technical specifications
1X230V
1x230V
F2040-6 / F2040-8 / F2040-12Compatible external parts
1)
F2120-8 / F2120-12 / F2120-16
NIBE SPLIT HBS 05 (AMS 10 + HBS 05)
Electrical data
7kWAdditional power
230V~50HzRated voltage
32AMax operating current
32AFuse
3 – 76WOutput, GP1
3 – 45WOutput, GP6
IP21Enclosure class
Heating medium circuit, hot water coil
low energyEnergy class, GP1
low energyEnergy class, GP6
70°CMax HM temp
Pipe connections
Ø22Heating medium
Ø22Hot water connection
Ø22Cold water connection
Ø22Heat pump connections
1)
Applies to an outdoor air heat pump at 7/45 °C (outdoor temperature/supply line temperature)
Other, indoor module
Capacity, hot water heating according to
EN16147
210lTap volume 40°C at Economy comfort
240lTap volume 40 °C during Normal comfort
280lTap volume 40 °C during Lux comfort
Dimensions and weight
600mmWidth
615mmDepth
1,800mmHeight (without base)
1,830 – 1,850mmHeight (with base)
1,910mmRequired ceiling height
124kgWeight (excl. packaging and without water)
069 112Part number Stainless steel - VVM 320 1x230V R UK
Type
1.6 (16)MPa (bar)Maximum water supply pressure
0.3 (3)MPa (bar)Operating pressure, tap water
0.35 (3.5)MPa (bar)Expansion vessel, tap water, precharge pressure
0.35 (3.5)MPa (bar)Pressure reduction valve, setting
176litresVolume, water heater
8litresVolume primary, Heating medium coil
22litresVolume, buffer vessel
25litresVolume expansion vessel (external)
330kgMass unit, filled with water
0.3 (3)MPa (bar)Operating pressure (heating medium)
0.7 (7)MPa (bar)Max operating pressure of T&P-valve
0.6 (6)MPa (bar)Set opening pressure expansion valve tap water
89CCut out, temperature limiter
NIBE VVM 320Chapter 12 | Technical data72
