Nibe VVM 320 Installer Manual

41 Important information
4Safety information
4Symbols
4Marking
5Serial number
5Recovery
5Country specific information
6Inspection of the installation
7Outdoor modules
82 Delivery and handling
8Transport
8Assembly
9Supplied components
10Removing the covers
123 Indoor module's design
13Component location, rear
13List of components
144 Pipe connections
14General pipe connections
17Dimensions and pipe connections
18Installation alternative
265 Electrical connections
26General
29Connections
32Settings
34Optional connections
37Connecting accessories
396 Commissioning and adjusting
39Preparations
39Filling and venting
40Start-up and inspection
42Setting the cooling/heating curve
44Setting hot water circulation
44Pool
45SG Ready
467 Control - Introduction
46Display unit
47Menu system
508 Control - Menus
50Menu 1 - INDOOR CLIMATE
51Menu 2 - HOT WATER
51Menu 3 - INFO
52Menu 4 - MY SYSTEM
53Menu 5 - SERVICE
639 Service
63Service actions
6710 Disturbances in comfort
67Info-menu
67Troubleshooting
6911 Accessories
7112 Technical data
71Dimensions and setting-out coordinates
72Technical specifications
74Electrical wiring diagram, 1x230 V
79Item register
3Table of ContentsNIBE VVM 320
Table of Contents

Nibe VVM 320 Specifications

General

Dimensions (HxWxD)	1800 x 600 x 615 mm
Power Supply	230 V
Frequency	50 Hz
Protection class	IP21
Compatible with	Nibe heat pumps
Display	Touch display
Smart Home Integration	Yes, via NIBE Uplink
Operating temperature	0°C to +45°C
Relative humidity	Max. 95 %
Type	Control unit for heat pumps
