Sub-menus
Menu SERVICE has orange text and is intended for the
advanced user. This menu has several sub-menus.
Status information for the relevant menu can be found
on the display to the right of the menus.
operating settings Operating settings for the indoor
module.
system settings System settings for the indoor module,
activating accessories etc.
accessory settings Operational settings for different
accessories.
soft in/outputs Setting software controlled in and out-
puts on the input circuit board (AA3).
factory setting service Total reset of all settings (includ-
ing settings available to the user ) to default values.
forced control Forced control of the different compon-
ents in the indoor module.
start guide Manual start of the start guide which is run
the first time when the indoor module is started.
quick start Quick starting the compressor.
NOTE
Incorrect settings in the service menus can
damage the installation.
MENU 5.1 - OPERATING SETTINGS
Operating settings can be made for the indoor module
in the sub menus.
MENU 5.1.1 - HOT WATER SETTINGS
VVM 320
economy
Setting range start temp. economy: 5 – 70 °C
Factory setting start temp. economy: 46 °C
Setting range stop temp. economy: 5 – 70 °C
Factory setting stop temp. economy: 49 °C
normal
Setting range start temp. normal: 5 – 70 °C
Factory setting start temp. normal: 49 °C
Setting range stop temp. normal: 5 – 70 °C
Factory setting stop temp. normal: 52 °C
luxury
Setting range start temp. lux: 5 – 70 °C
Factory setting start temp. lux: 55 °C
Setting range stop temp. lux: 5 – 70 °C
Factory setting stop temp. lux: 58 °C
stop temp. per. increase
Setting range: 55 – 70 °C
Factory setting: 55 °C
Here you set the start and stop temperature of the hot
water for the different comfort options in menu 2.2 as
well as the stop temperature for periodic increase in
menu 2.9.1.
MENU 5.1.2 - MAX FLOW LINE
TEMPERATURE
climate system
Setting range: 5-80 °C
Default value: 60 °C
Set the maximum supply temperature for the climate
system here. If the installation has more than one cli-
mate system, individual maximum supply temperatures
can be set for each system. Climate systems 2 - 8 can-
not be set to a higher max supply temperature than cli-
mate system 1.
Caution
Underfloor heating systems are normally max
flow line temperature set between 35 and 45
°C.
Check the max floor temperature with your
floor supplier.
NIBE VVM 320Chapter 8 | Control - Menus54
