18 - GENERAL LAYOUT AND SAFETY ACCESS
Entrapment Protection Inputs - Typical Installation Diagram Utilizing Loop Sensors and Photocells
Figure - LAYOUT FOR IN-GROUND LOOPS
Entrapment Protection Inputs - Typical Installation Diagram Utilizing Photocells
Figure - LAYOUT FOR PHOTOCELLS
Loop (safety)
Loop (shadow)
Loop (safety)
Loop (exit)
Photo 2 Photo 2
4’ min. from closed gate
4’ min. from closed gate
Photo 2 Photo 2
Photo 1
