To set multiple parameters during the procedure's execution, repeat the operations from point 2 to point 4 dur-
ing the phase itself.
l
The set value highlighted in grey (“Table 6”) indicates that this value is the factory setting.
Table 6
LEVEL 2 FUNCTIONS (ADJUSTABLE PARAMETERS)
Entry
LED
Parameter
LED
(level)
Set value Description
L1 Pause Time
L1 5 seconds
Adjusts the pause time, in other words,
the time that elapses before automatic
re-closure. It is only effective if the Close
function is enabled.
L2 15 seconds
L3 30 seconds
L4 45 seconds
L5 60 seconds
L6 80 seconds
L7 120 seconds
L8 180 seconds
L2
Step-by-Step
function
L1 Open - Stop - Close - Stop
Controls the sequence of commands
associated with the “SbS”, “Open” and
“Close” inputs or the radio control.
Note:
setting L4, L5, L7 and L8, the behaviour
of the “Open” and “Close” commands
also changes.
L2 Open - Stop - Close - Open
L3 Open - Close - Open - Close
L4
CONDOMINIUM
During the opening manoeuvre, the “Step-by-Step”
and “Open” commands do not cause any effect; instead
the “Close” command causes the movement to reverse,
namely the closing of the gate leaves.
During the closing manoeuvre, the “Step-by-Step” and
“Open” commands cause a reversal of the movement,
namely the opening of the gate leaves; instead the
“Close” command does not cause any effect.
L5
CONDOMINIUM 2
During the opening manoeuvre, the “Step-by-Step”
and “Open” commands do not cause any effect;
instead the “Close” command causes the movement to
reverse, namely the closing of the gate leaves. If the sent
command remains for more than 2 seconds, a “Stop”
command is executed.
During the closing manoeuvre, the “Step-by-Step” and
“Open” commands cause a reversal of the movement,
namely the opening of the gate leaves; instead the
“Close” command does not cause any effect. If the sent
command remains for more than 2 seconds, a “Stop”
command is executed.
L6
STEP-BY-STEP 2 (less than 2 seconds causes partial
opening)
L7
HOLD-TO-RUN
The manoeuvre is only executed if the sent command
remains; if the command is interrupted, the manoeuvre
stops.
L8 “Semi-automatic” opening, “hold-to-run” closing.
L3 Opening delay
L1 0%
Adjusts the opening delay for the lower
leaf motor: It can be programmed as a
percentage of the work time.
L2 10 %
L3 15 %
L4 20 %
L5 25 %
L6 30 %
L7 40 %
L8 50 %
L4 Closing delay
L1 0%
Adjusts the closing delay for the upper
leaf motor. It can be programmed as a
percentage of the work time.
L2 10 %
L3 15 %
L4 20 %
L5 25 %
L6 30 %
L7 40 %
L8 50 %
