14 – ENGLISH
7.2 LEVEL 1 PROGRAMMING (ON-OFF)
All the Level 1 functions are factory-set to “OFF” and can be modied at any time. To check the various functions, refer to “Table 6”.
7.2.1 Level 1 programming procedure
m
The user has maximum 10 seconds to press the buttons consecutively during the programming procedure,
after which time the procedure terminates automatically and memorises the changes made up to then.
To perform Level 1 programming:
1. press and hold the
g
button until LED “L1” starts ashing
2. release the
g
button when LED “L1” starts ashing
3. press the
f
or
h
button to move the ashing LED to the LED associated with the function to be modied
4. press the
g
button to change the status of the function:
– short ash = OFF
– long ash = ON
5. wait 10 seconds (maximum time) to exit the programming mode.
l
To set other functions to “ON” or “OFF”, while the procedure is running, repeat points 2 and 3 during the phase
itself.
Table 6
LEVEL 1 FUNCTIONS (ON-OFF)
LED Function Description
L1 Automatic closing
Function ENABLED: after an opening manoeuvre there is a pause (equal to the set pause time), after
which the control unit automatically starts a closing manoeuvre. The pause time is set by default to 30
seconds.
Function NOT ENABLED: the system works in “semi-automatic” mode.
L2 Close after photo
Function ENABLED: the behaviour changes depending on whether the “Automatic Closing” function is
enabled or not.
With “Automatic Closing” disabled: the gate will always reach the fully open position (even if the photocell
disengages before). The disengaging of the photocell triggers the automatic re-closing after a 5-second
pause.
When “Automatic Closing” is enabled: the opening manoeuvre stops immediately after the photocells have
disengaged. After 5 seconds, the gate will start closing automatically.
The “Close After Photo” function is always disabled in manoeuvres interrupted by a Stop command.
Function DISABLED: the pause time is that which has been programmed or automatic re-closing will not
take place if the function is disabled.
L3 Always Close
Function ENABLED: in the event of a blackout, even of short duration, if the control unit detects that the
gate is open when the electricity is restored, it automatically starts a closing manoeuvre preceded by a
5-second pre-ash.
Function DISABLED: when the electricity is restored, the gate remains in the same position.
L4 Stand-by
Function ENABLED: 1 minute after the completion of the manoeuvre, the control unit switches off the
BlueBUS output (and, therefore, the devices) and all LEDs, with the exception of the BlueBUS LED, which
ashes more slowly. When the control unit receives a command, it restores full operation.
Function DISABLED: there will be no reduction in consumption.
This function is useful, in particular, during operation with the back-up battery.
L5 Peak
Function ENABLED: the gradual acceleration at the beginning of each manoeuvre will be disengaged; it
allows for having peak thrust and is useful whenever static friction is high, e.g. if snow or ice are blocking
the gate.
Function DISABLED: the manoeuvre will start with a gradual acceleration.
L6 Pre-ashing
Function ENABLED: a 3-second pause can be added between the switching on of the warning light and
the start of the manoeuvre, to warn the user in advance of a potentially dangerous situation.
Function DISABLED: the signalling of the warning light coincides with the start of the manoeuvre.
L7
“Close” becomes
“Partial Open”
Function ENABLED: the “Close” input of the control unit switches its operation to “Partial Open”.
L8 “Slave” mode
Function ENABLED: it is possible to synchronise the functioning of 2 motors on opposite leaves where
one motor functions as master and the other as slave; for further information, refer to the “Gearmotor in
SLAVE mode” paragraph.
l
During normal operation, LEDs “L1 ... L8” are on/off depending on the status of the respective function; for
example, “L1” is lit when the “Automatic Closing” function is enabled.
