TECHNICAL SPECIFICATIONS
12
12 TECHNICAL SPECIFICATIONS
l
All technical specications stated in this section refer to an ambient temperature of 20°C (± 5°C). Nice S.p.A.
reserves the right to apply modications to the product at any time when deemed necessary, without altering
its functions and intended use.
Table 19
TECHNICAL SPECIFICATIONS
Description Technical specication
Product type Electromechanical gearmotor for sectional doors
Power supply
120Va (+10% -15%) 60Hz
Maximum current draw (A) 3,0
Nominal current draw (A) 2
Maximum torque (Nm) 50
Rated torque (Nm) 30
Maximum power consumption (W) 350
Nominal power consumption (W) 220
Maximum speed (rpm) 30
Nominal speed (rpm) 18
Static holding torque (Nm) 130
Protection rating (IP) 40
Operating temperature (min/max °C) -20°C ÷ 50°C
Maximum door surface area 215ft2 40in2 1/16 (20 mq)
Maximum door height 16ft 4in 55/64 (5 m)
Insulation class I
Durability
Estimated between 40,000 and 120,000 cycles, depending on the
conditions specied in the “Product durability” paragraph
Cycles per hour at the rated torque – for doors with 3 m
height (cycles/hour)
15
Dimensions 4in 1/2 x 14in 3/4 x 11in 13/16 (115x375x300 mm)
Weight 23 lb (10,5 Kg)
Hole 1in (25,5 mm)
Emergency power supply Yes (PS124 battery)
Courtesy light Integrated with LED
Warning light output [Note 1] For 1 LUCYB warning light; MLB or MLBT (12 V, 21 W lamp)
ALARM output [Note 1] for 24Vdc 108dB Siren
BLUEBUS output One output with maximum load of 12 BlueBUS units
STOP input
For normally closed or normally open contacts or for 8.2 kΩ xed resistor
contacts with self-learning (any variation from the memorised status
triggers the STOP command, and with the alarm system triggered, allows
the automation to be released)
Sbs input [Note 2]
For normally open contacts (the closing of the contact triggers the STEP-
BY-STEP command, and with the motor stopped and the alarm system
triggered, allows the automation to be released)
OPEN input [Note 2]
For normally open contacts (closing of the contact triggers the “OPEN”
command)
LIGHT input [Note 2]
For normally open contacts (the closing of the contact causes the
Courtesy Light status to switch)
Radio ANTENNA input 52 Ω for RG58-type cable or similar
Programming input For 1 OVIEW programmer with 4-pin telephone cable and RJ14 connector
Radio connector SM connector for SMXI, SMXIS or OXI receivers
Programmable functions 8 ON-OFF and 8 adjustable functions
Self-learning functions
Self-learning of the devices connected to the BlueBus output
Self-learning of the type of “STOP” device (Normally Open, Normally
Closed contact or 8.2 kΩ resistor)
Use in highly acid, saline or potentially explosive
atmosphere
No
Note 1 The output can be programmed with other functions (see “Table 9” or through the Oview programmer).
Note 2 The inputs can be programmed with other functions through the Oview programmer.
