112 Unidrive M / HS Frame 7 to 10 Power Installation Guide
*Resistor tolerance: ±10 %. The minimum resistance specified are for stand-alone drive systems
only. If the drive is to be used as part of a common DC bus system different values may be required.
Contact the supplier of the drive for more information.
09402240 (9A) 3.6 187.8 110
09402000 (9E) 2.6 260 90
09402240 (9E) 2.6 260 110
10402700 3.1 218.1 132
10403200 3.1 218.1 160
575 V
07500440 11 87.4 30
07500550 11 87.4 37
08500630 5.5 174.8 45
08500860 5.5 174.8 55
09501040 (9A) 5.1 188.5 75
09501310 (9A) 5.1 188.5 90
09501040 (9E) 3.3 291.3 75
09501310 (9E) 3.3 291.3 90
10501520 3.3 291.3 110
10501900 3.3 291.3 132
690 V
07600190 13 107.3 15
07600240 13 107.3 18.5
07600290 13 107.3 22
07600380 13 107.3 30
07600440 13 107.3 37
07600540 13 107.3 45
08600630 5.5 253.5 55
08600860 5.5 253.5 75
09601040 (9A) 6.5 214.5 90
09601310 (9A) 6.5 214.5 110
09601040 (9E) 4.2 331.9 90
09601310 (9E) 4.2 331.9 110
10601500 4.2 331.9 132
10601780 3.8 366.8 160
Model
Minimum resistance
*
Instantaneous power rating Continuous power rating
Ω kW kW
