16 Unidrive M / HS Frame 7 to 10 Power Installation Guide
2.3 Nameplate description
Figure 2-2 Typical drive rating labels
Refer to Figure 2-1 Model number on page 15 for further information relating to the labels.
Date code format
The date code is four numbers. The first two numbers indicate the year and the
remaining numbers indicate the week of the year in which the drive was built.
Example:
A date code of 1710 would correspond to week 10 of year 2017.
M600-094 02240 E10
Model
Frame
Voltage
Heavy Duty
current rating
Power
format
Control pod fitted
Fan power
supply fitted
Refer to
User Guide
Normal/Heavy
Duty power rating
Approvals
Input phases & input current
Output phases & Heavy
Duty/Normal Duty rating
Serial number
Input voltage
Output voltage
Date code
110/132kW 1710
Model
Approvals
Input phases & input current
Output phases & Heavy
Duty/Normal Duty rating
Serial number
Input voltage
Output voltage
Date code
M600-094 02240 E10
110/132kW
1710
Input frequencyInput frequency
Key to approvals
CE approval Europe
RCM regulatory
compliance mark
Australia
UL / cUL approval USA & Canada
RoHS compliant Europe
Functional safety USA & Canada
Eurasian conformity Eurasia
R
NOTE
