5.2 Optional external EMC filters
Table 5-37 EMC filter cross reference
5.2.1 EMC filter ratings
Table 5-38 Optional external EMC filter details
5.2.2 Overall EMC filter dimensions
Table 5-39 Optional external EMC filter dimensions
Model CT part number
200 V
05200250 4200-0312
06200330 to 06200440 4200-2300
400 V
05400270 to 05400300 4200-0402
06400350 to 06400470 4200-4800
575 V
05500030 to 05500069 4200-0122
06500100 to 06500350 4200-3690
Part
number
Maximum
continuous
current
Voltage
rating
IP
rating
Power
dissipation at
rated current
Ground leakage
Discharge
resistors
Balanced
supply
phase-to-
phase and
phase-to-
ground
Worst
case@ 40 °C
(104 °F)
@ 50 °C
(122 °F)
IEC UL
@ 40 °C
(104 °F)
@ 50 °C
(122 °F)
A A V V W W mA mA M
4200-0312 31 28.5 250 300
20
20 17 2.0 80
1.68
4200-2300 55 51 250 300 41 35 4.2 69
4200-0402 40 36.8 528 600 47 40 18.7 197
4200-4800 63 58 528 600 54 46 11.2 183
4200-0122 12 11 760 600
9 9 15.2 285
4200-3690 42 39 760 600 45 39 12 234
Part
number
Dimension (mm)
Weight
HWD
mm inch mm inch mm inch kg lb
4200-0312 437 17.20 143 5.63 60 2.36 5.5 12.13
4200-2300 434 17.09 210 8.27 60 2.36 6.5 14.30
4200-0402 437 17.20 143 5.63 60 2.36 5.5 12.13
4200-4800 434 17.09 210 8.27 60 2.36 6.7 14.80
4200-0122 437 17.20 143 5.63 60 2.36 5.5 12.13
4200-3690 434 17.09 210 8.27 60 2.36 7.0 15.40
