2.5 Drive features
Figure 2-3 Features of the drive power section
Key
1. Braking terminal (for external brake resistor)
2. Internal EMC filter
3. DC bus +
4. DC bus -
5. Motor connections
6. AC supply connections
7. Ground connections
8. Braking terminal for heatsink mounted brake resistor (size 5 only, M600 and above)
15
3
4
1
8
4
15
3
7
6
5
4
3
1
6
5
7
2
2
