70 Unidrive M/HS Frame 5 to 6 Power Installation Guide
Issue Number: 9
Figure 4-11 Installation of grounding clamp (size 6)
The grounding clamp is secured using the provided 2 x M4 x 10 mm fasteners. The fasteners should
be tightened with the maximum torque of 2 N m (1.47 Ib ft).
