92 Unidrive M / HS Frame 7 to 10 Power Installation Guide
5 Technical data
5.1 Drive technical data
5.1.1 Power and current ratings
For a full explanation of ‘Normal Duty’ and ‘Heavy Duty’ refer to the Control User Guide.
The continuous current ratings given are for maximum 40 °C (104 °F), 1000 m altitude and 3 kHz
switching frequency (unless stated otherwise). Derating is required for higher switching frequencies,
ambient temperature >40 °C (104 °F) and high altitude. For further information, refer to Power and
current ratings (Derating for switching frequency and temperature) on page 94.
Table 5-1 200 V drive ratings (200 V to 240 V ±10 %)
Table 5-2 400 V drive ratings (380 V to 480 V ±10 %)
* These ratings are for 2 kHz switching frequency. For ratings at 3 kHz switching frequency refer to
section 5.1.2 Power and current ratings (Derating for switching frequency and temperature) on
page 94.
Model
Normal Duty Heavy Duty
Max
cont
output
current
Nominal
power
at 230 V
Motor
power
at 230 V
Peak
current
Max
cont
output
current
Open
loop
peak
current
RFC
peak
current
Nominal
power
at 230 V
Motor
power
at 230 V
AkWhpAA A AkW hp
07200610 75 18.5 25 82.5 61 91.5 122 15 20
07200750 94 22 30 103.4 75 112.5 150 18.5 25
07200830 117 30 40 128.7 83 124.5 166 22 30
08201160 149 37 50 163.9 116 174 232 30 40
08201320 180 45 60 198 132 198 264 37 50
09201760 216 55 75 237.6 176 264 308 45 60
09202190 266 75 100 292.6 219 328.5 383.25 55 75
10202830 325 90 125 357.5 283 424.5 495.25 75 100
10203000 360 110 150 396 300 450 525 90 125
Model
Normal Duty Heavy Duty
Max
cont
output
current
Nominal
power
at 400 V
Motor
power
at 460 V
Peak
current
Max
cont
output
current
Open
loop
peak
current
RFC
peak
current
Nominal
power
at 400 V
Motor
power
at 460 V
AkWhp A A AAkW hp
07400660 79 37 60 86.9 66 99
132 30 50
07400770 94 45 60 103.4 77 115.5
154 37 60
07401000 112 55 75 123.2 100 150
200 45 75
08401340 155 75 100 170.5 134 201
268 55 100
08401570 184 90 150 202.4 157 235.5
314 75 125
09402000 221 110 150 243.1 200* 300
350 90 150
09402240 266* 132 200 292.6 224* 336
392 110 150
10402700 320 160 250 352 270 405
472.5 132 200
10403200 361 200 300 397.1 320* 480
560 160 250
