Unidrive M/HS Frame 5 to 6 Power Installation Guide 91
Issue Number: 9
Safety information Product information Mechanical installation Electrical installation
Technical data
UL listing information
Table 5-11 2 % line reactors
5.1.7 Motor requirements
No. of phases: 3
Maximum voltage:
200 V drive: 240 V
400 V drive: 480 V
575 V drive: 575 V
5.1.8 Storage
-40 °C (-40 °F) to +55 °C (131 °F) for long term storage, or to +70 °C (158 °F) for short term storage.
Storage time is 2 years.
Electrolytic capacitors in any electronic product have a storage period after which they require
reforming or replacing.
The DC bus capacitors have a storage period of 10 years.
The low voltage capacitors on the control supplies typically have a storage period of 2 years and are
thus the limiting factor.
Low voltage capacitors cannot be reformed due to their location in the circuit and thus may require
replacing if the drive is stored for a period of 2 years or greater without power being applied.
It is therefore recommended that drives are powered up for a minimum of 1 hour after every 2 years
of storage. This process allows the drive to be stored for a further 2 years.
Drive
model
number
Voltage
rating
Line reactor
designation
CT Part
number
Line
reactor
current
rating
Inductance Weight Length Width Height
V A mH kg mm mm mm
05200250 200 INL2008 4401-0226 32 0.26 3.30 156 60 145
06200330 200 INL2004 4401-0146 48.8 0.17 4.8 156 75 145
06200440 200 INL2005 4401-0147 56.6 0.15 4.9 156 120 130
05400270 400 INL4013 4401-0236 32 0.48 4.9 156 75 145
05400300 400 INL4013 4401-0236 32 0.48 4.9 156 75 145
06400350 400 INL4006 4401-0154 36.5 0.4 8 206 140 200
06400420 400 INL4007 4401-0155 46.2 0.32 9 206 140 200
06400470 400 INL4008 4401-0156 60.6 0.24 11 255 125 195
05500030 575 INL5007 4401-0242 4.3 4.92 1.4 80 75 130
05500040 575 INL5008 4401-0243 6.8 3.11 1.8 156 70 125
05500069 575 INL5009 4401-0244 11.4 1.89 3.2 156 60 145
06500100 575 INL5001 4401-0157 13.2 1.6 3.5 156 60 145
06500150 575 INL5002 4401-0158 18.7 1.13 4.9 156 75 145
06500190 575 INL5003 4401-0159 24.3 0.87 6 206 95 200
06500230 575 INL5004 4401-0160 29.4 0.72 7.4 206 130 200
06500290 575 INL5005 4401-0161 37.1 0.57 11 230 130 210
06500350 575 INL5006 4401-0223 47 0.48 12.5 230 130 210
