116 Unidrive M / HS Frame 7 to 10 Power Installation Guide
Table 5-35 Size 8 emission compliance (400 V drives)
Table 5-36 Size 8 emission compliance (575 V and 690 V drives)
Table 5-37 Size 9 and 10 emission compliance (200 V drives)
Table 5-38 Size 9 and 10 emission compliance (400 V drives)
Table 5-39 Size 9 and 10 emission compliance (575 V and 690 V drives)
Motor cable length (m)
Switching Frequency (kHz)
2346 81216
Using internal filter:
0 – 10
C3 C3 C3 C3 C3 C3 C3
Using external filter:
0 – 20
C2 C2 C2 C2 C2 C2 C2
20 – 100
C2 C2 C3 C3 C3 C3 C3
Motor cable length (m)
Switching Frequency (kHz)
2346 81216
Using internal filter:
0 – 100
C4 C4 C4 C4 C4 C4 C4
Using external filter:
0 – 20
C2 C2 C2 C2 C2 C2 C2
20 – 100
C2 C2 C3 C3 C3 C3 C3
Motor cable length (m)
Switching Frequency (kHz)
2346 81216
Using internal filter:
0 – 100
C3 C3 C3 C3 C3 C3 C3
Using external filter:
0 – 20
C2 C2 C2 C2 C2 C2 C2
20 – 100
C2 C2 C3 C3 C3 C3 C3
Motor cable length (m)
Switching Frequency (kHz)
2346 81216
Using internal filter:
0 – 100
C3 C3 C3 C3 C3 C3 C3
Using external filter:
0 – 20
C2 C2 C2 C2 C2 C2 C2
20 – 100
C2 C2 C3 C3 C3 C3 C3
Motor cable length (m)
Switching Frequency (kHz)
2346 81216
Using internal filter:
0 - 50
C3 C3 C3 C3 C3 C3 C3
Using external filter:
0 – 20
C2 C2 C2 C2 C2 C2 C2
20 – 100
C2 C2 C3 C3 C3 C3 C3
