Unidrive M / HS Frame 7 to 10 Power Installation Guide 119
Safety information Product information Mechanical installation Electrical installation
Technical data
UL listing information
5.2.2 Overall EMC filter dimensions
Table 5-42 Optional external EMC filter dimensions
5.2.3 EMC filter torque settings
Table 5-43 Optional external EMC Filter terminal data
Part Number
Dimensions (mm)
Weight
HW D
mm inch mm inch mm inch kg lb
4200-1132 270 10.63 90 3.54 150 5.90 6 13.2
4200-0672 270 10.63 90 3.54 150 5.90 6.2 13.7
4200-1972 300 11.81 120 4.72 170 6.69 9.6 21.2
4200-1662 300 11.81 120 4.72 170 6.69 9.4 20.7
4200-3021 339 13.3 230 9.06 120 4.72 11 24.3
4200-1660 360 14.2 245 9.6 105 4.13 5.2 11.5
4200-4460 105 4.13 360 14.2 245 9.6 12 26.5
4200-2210 105 4.13 360 14.2 245 9.6 10.3 22.7
CT part
number
Power
connections
Ground
connections
Bar hole diameter Max cable size Max torque
Ground stud
size
Max torque
4200-1132
N/A
50 mm
2
(1/0 AWG)
8.0 N m
(6.0lb ft)
M10
18 N m
(13.3 lb ft)
4200-0672
4200-1972
95 mm
2
(3/0 AWG)
20 N m
(14.8 lb ft)
4200-1662
4200-3021 10.8 mm
N/A
30 N m
(22.1 lb ft)
4200-1660 10.8 mm
4200-4460 11 mm
4200-2210 11 mm
