Unidrive M/HS Frame 5 to 6 Power Installation Guide 47
Issue Number: 9
Safety information Product information
Mechanical installation
Electrical installation Technical data UL listing information
Figure 3-26 Removal of the size 6 auxiliary fan
• Press the tabs (1) inwards to release the fan assembly from the drive mid cover.
• Use the tabs (1) to withdraw the fan from the drive by pulling the fan assembly forward and tilting
it at a slight angle (2).
• Pull the fan assembly up and away from the drive (3).
• Depress and hold the locking release on the fan cable lead.
• With the locking release depressed, take hold of the fan supply cable and carefully pull to
separate the connectors.
Replace the fan by reversing the above instructions.
Figure 3-27 Fan part numbers
Model Heatsink fan part number Auxiliary fan part number
Size 5 3251-0245 N/A
Size 6 3251-0030 3251-0030
