Nikon Communication Interface Manual
7. SET2Way Emulation
Following commands are supported by Nikon DTM-502/501/350/330/352/332 ,
NPL-350/352/332 and Nivo M series.
Command 501/500/350/330 502/352/332 Note
%
Change mode to Theodolite mode O O
An exit from HA setout (Gd)
Jumps to the BMS
/B
Set Instrument’s parameter settings ACK O Prism const set on MSR key
/Da
Set Instrument’s coordinates - O
/Db
Set Distance and HA setout data ACK O Jumps to the Stakeout screen
/Dc
Set HA to the requested value O O
/Dd
Set Coordinates of Backsight point - O
/De
Set HI, HT and T&P data ACK O
/Df
Set Coordinates for setout data - O
/Dg
Set Coordinate data - -
A
Output Instrument ID O O
B
Output Instrument’s parameter settings O O
Db
Output Distance and HA setout data - O
De
Output HI, HT, T&P and ppm - O Different from ppm(Nikon)
Ea
SD/VA/HA measurement O O
Ec
Tilt angle measurement - -
Ed
N, E and Z coordinate measurement - O
Ee
Get HA, VA and tilt (XY) data O O
Gb
HD set-out measurement - O
Gd
HA set-out measurement ACK O Jumps to the Stakeout screen
Gf
SET 2 way, setout VD ACK O Jumps to the Stakeout screen
Xa
Single fine measure - O
Xb
Repeat fine measure, until <12h> - O
Xc
Single coarse measure - O
Xd
Xe
Repeat coarse measure, until <12h> - O
Xf
Xg
Change mode to Theodolite mode ACK ACK
Jumps to the BMS
Xi
Calculate backsight direction - O
Xk
Set HA clockwise (HAR) ACK ACK
Xl
Delete all coordinates in memory - -
O: Supported
- : Not supported
ACK: Return ACK only
P34/34
